Model

TNM-2L-H 300 m/min Double Tracks 1/4 Quarterfold Paper Napkin Machine with Automatic High Speed Serviette Tissue Folding Converting Making Printing Embossing Function copied Italy technology

Output type

2 tracks/layers (4 lanes) Output Delivery,

1 or 2 Decks delivery machine available.

Capacity

about 1500 sheet/min/track x 2 tracks/layers = 3000 sheet/min total, depending on the paper quality and napkin size etc.

Raw paper

13-20g/m2 2-ply, 20-35g/m2 1-ply, wooden pulp paper or to be specified.

Other sizes likenonwoven or airlaid please specify.

Jumbo roll size

Φ1200x(200-460)x3 (Depending on your napkin size,customized)

Napkin unfolded size

200mm x 200mm to 460mm x 460mm  or Customized.

Napkin folded size

100mm x 100mm to 230mm x 230mm

One size is fixed.

One napkin size is adjustable, decided by the paper roll width.

Folding type

Mechanical fold;
1/4 fold; Quarter fold. single sheet V fold, 1/2 fold, 1/6 fold, 1/8 fold etc. or customized.
Vacuum folding and other folding types available.

Folding Section

With folding fingers.

With automatic counting system, one tissue will pop up every count of 50, 100, 150,200 sheets etc.

The gap between folding rollers can be adjusted to adapt the machine to papers of different quality and gsm.

Easy operation and adjustment.

Embossing Section

1- Steel to paper(wool-coated), Male to female.  (Steel to steel is available.)

2- Embossing pattern can be customized any LOGO, brand name, flowers etc.

3- Embossing pattern can be customized by client or recommended by us

4- Controlled by screws, mechanical pressing type. Cylinder type is optional.

5- We have innovated NEW Embossing Technology which can make the embossing pattern transparent very attractive. Please contact us for more details.

Printing Section

With 2 colors(2 sets) flexo-graphic printer section. 2, 3, 4 colors optional.

Printing colors customized up to 8 colors. The other model.

Printing Logo is changeable. You just need to change the Printing Rubber only.

Printing rollers can be adjusted flexibly and easily.

With anilox roller.

Printing unit with driven by timing belts to make printing more precise.

Between printing color to color location which will accept ±1-2 mm tolerance.

With New Register device, Register adjustment color to color position will use 360° rotation speed modulators device which is easy to adjust.

Simple and easy adjustment of horizontal and longitudinal registration by turning hand wheel.

Unwind stand

With 1 unwind stand, controlled by pneumatic cylinders, with feeding belt.

With pneumatic system to load the jumbo rolls automatically.

With paper web tension control systems to adept the machine to jumbo rolls of different quality and gsm.

Equipped with hand wheel or independent motor to adjust the jumbo roll to the left/right.

Equipped with sensors to dectect the jumbo roll, if finished, machine will automatically alarm and stop.

Auto Web tension control system is optional.

Auto edge guiding system is optional..

Control system

Main motor controlled by inverter, international brands from Taiwan, Japan, Germany etc.
Frequency speed control
With JOG devices (step by step for passage and adjusting paper).
Emergency stop if paper breaks or finished.
Start machine with alarm beeper.
Air pressure:0.5Mpa

Installed Power

7.5KW. 3phase AC380V 50Hz or 3phase 220V,60Hz or 3phase 440V 60Hz or customized

Machine size

7x1.5x2.1(m)

Weight

4000KG
